Soluzione Per Gruppo Elettrogeno A Metanolo E Idrogeno
Soluzione Per Gruppo Elettrogeno A Metanolo E Idrogeno
Soluzione Per Gruppo Elettrogeno A Metanolo E Idrogeno
Soluzione Per Gruppo Elettrogeno A Metanolo E Idrogeno
Soluzione Per Gruppo Elettrogeno A Metanolo E Idrogeno
Soluzione Per Gruppo Elettrogeno A Metanolo E Idrogeno
Soluzione Per Gruppo Elettrogeno A Metanolo E Idrogeno
Soluzione Per Gruppo Elettrogeno A Metanolo E Idrogeno

Soluzione Per Gruppo Elettrogeno A Metanolo E Idrogeno

Quantità di ordine minimo:1
use:
  • Other
fuel:
  • Methanol

  • Caratteristiche del prodotto
  • Confezionamento e consegna
  • Descrizione del prodotto
  • Capacità di fornitura e informazioni ag...
  • Other information
Caratteristiche del prodotto

ModelloGS14M440HF-45

marchioFarizon

OriginGuangzhou, Guangdong, Cina

Servizio Fuori GaranziaSupporto tecnico video, Supporto online

Vecchio E NuovoNuovo

Numero Di CilindriMulticilindrico

Metodo Di RaffreddamentoAcqua raffreddata

Luogo D'origineCina

Periodo Di Garanzia1 anno

Sistema Di ServiziSupporto di terze parti all'estero disponibile

Standard Di Emissionealtro

Rapporto Di Prova MeccanicaFornito

Video Ispezione In FabbricaFornito

Periodo Di Garanzia Dei Componenti Principali1 anno

Confezionamento e consegna

The file is encrypted. Please fill in the following information to continue accessing it

Descrizione del prodotto

La prima soluzione al mondo per il generatore di idrogeno alcolico

La soluzione del generatore di idrogeno alcolico FARIZON adotta il generatore di idrogeno alcolico GS14m440HF-45 come nucleo, integra un efficiente sistema di accumulo di energia e fornisce due configurazioni: unità a scatola singola da 300 kW e unità doppia da 600 kW, soddisfacendo pienamente i requisiti dello standard G2. La velocità nominale del motore è di 1500 giri/min, la potenza nominale è di 324 kW, la potenza in standby è di 356 kW e il design di grande cilindrata da 13,67 litri garantisce una potenza stabile e affidabile.

Questa soluzione integra in modo innovativo la tecnologia energetica del combustibile a metanolo e dell’idrogeno, con caratteristiche di basse emissioni di carbonio e rispettose dell’ambiente, ed è adatta a scenari come data center e parchi industriali. Il sistema di controllo intelligente consente una regolazione precisa della potenza, supporta l'implementazione rapida e il monitoraggio remoto e offre ai clienti una garanzia di energia efficiente e pulita.

2
Engine Brand/Model GS14M440HF-45
Rated revolution (rpm) 1500
Rated power (kW) 324
Standby power (kW) 356
Discharge capacity (L) 13.67
Generator set Category 300KW single-box unit 600KW single-box unit Parameters of energy storage system
Rated power (kW/kVA) 280/350 550/687.5 System capacity: 282kWh * 4
Standby power (kW/kVA) 308/385 600/750 Maximum charging power of battery pack: 125kW * 4
Number of phases Three-phase four-wire system Three-phase four-wire system Maximum discharge power of battery pack: 125kW * 4
Power factor PF=0.8 PF=0.8 DC operating voltage range: 580V~1000V
Voltage (V) 400/230 400/230 Maximum AC output power: 500kW
Current (A) 445 900 Rated AC voltage: 400V
Voltage adjustment range ≥ ±5% ≥ ±5% Rated AC current: 728A
Steady-state voltage regulation rate ≤ ±1% ≤ ±1% Rated AC frequency: 50Hz/60Hz
Transient state performance Meet G2 standard Meet G2 standard Apparent power of isolation transformer: 500kVA
External dimension (mm) 4250*1500*2500 5200*3000*3000 ——

Capacità di fornitura e informazioni ag...

Luogo di origineGuangzhou, Guangdong, Cina
